Van giảm áp gas Geca DN65-DN80-DN100- Pmax 5bar
Thông số kỹ thuật
– Pmax inlet max – 5 bar
– Setting outlet 10 – 300 mbar – Standard spring supplied 10-27 mbar
– Filtering ≤ 50μm – Viledon cartridge
– Inlet – Outlet Flanged connection DN65
– Connection DN80 – DN100 – PN16
– Test point Inlet / outlet on request . Test point 1/8h NPT
– Working Temperature – 20° C -+ 60° C
– Use Not aggressive gases of three families – Natural Gas – LPG – Town Gas
– Complete Body Die – Cast Aluminium Gd – AlSi12Cu – EN AB 46100
– Diaphragms NBR 60Sh – DvGW EN 549
– Plastic components Yellow POM / Pa 66 + 25% Gf
– Approval UNI EN 88-2:2008 PED
Options
– Color: White Range: 5 – 14 mbar
– Color: Yellow Range: 6 – 22 mbar
– Color: Neutral Range: 10 – 27 mbar
– Color: Red Range: 28 – 70 mbar
– Color: Black Range: 60 – 130 mbar
– Color: Blue Range: 120 – 300 mbar
Model
TYPE
|
DIMENSIONS
|
DESCRIPTION
|
P MAX
|
---|---|---|---|
RGD100-5B
|
DN100
|
GAS GOVERNOR
|
5 BAR
|
RGD100-FT-5B
|
DN100
|
GAS GOVERNOR WITH FILTER
|
5 BAR
|
RGD65-5B
|
DN65
|
GAS GOVERNOR
|
5 BAR
|
RGD65-FT-5B
|
DN65
|
GAS GOVERNOR WITH FILTER
|
5 BAR
|
RGD80-5B
|
DN80
|
GAS GOVERNOR
|
5 BAR
|
RGD80-FT-5B
|
DN80
|
GAS GOVERNOR WITH FILTER
|
5 BAR
|
Pressure drop table
Dimensions
